I-OEM Ikhwalithi Ephezulu140MM 160MM 168MM 200MM Insimbi Engagqwali ye-UPVC Usayizi Omkhulu Webhola Valve Yephrojekthi DN200

Incazelo emfushane:

I-valve yebhola
1.Imibala ethambile kanye nomklamo ohlangene
2.Ukusebenza kweLeakproff;
I-3.Light kanye neziphetho zenyunyana zenza ukufakwa kube lula
I-4.Economic njengezindleko zokuthutha ezishibhile nempilo ende yokusebenza
5.Well kanye nokulawula izinga eliphezulu
6.Imvelo inobungane, ayinabo ubuthi
7.Weathering & Abrasion ukumelana & omuhle kakhulu ukumelana namakhemikhali
8.Isetshenziswa kabanzi ekwakheni, ekucheleleni, embonini nase-swimming pool
9.I-oda elincane liyamukeleka
10.Idizayini nelogo yekhasimende wamukelekile


  • Usayizi:140MM 160MM 168MM 200MM
  • Ukuphela Okuhlangene:I-ASTM BS DIN ISO JIS
  • Ingcindezi Yokusebenza:I-PN16
  • Imininingwane Yomkhiqizo

    FAQ

    Omaka bomkhiqizo

    Imephu yenganekwane neyomzimba

    i-singleproducimg

    Impahla yengxenye

    ukucaciswa kwempahla

    CHA. Ingxenye Okubalulekile QTY
    1 UMZIMBA I-UPVC, i-CPVC 1
    2 STEM O-Ring I-EPDM,FPM(NBR) 1
    3 STEM I-UPVC, i-CPVC 1
    4 IBHOLA I-UPVC, i-CPVC 1
    5 SEAT SEAL TPE,TPVC,TPO 2
    6 I-CAP I-PVC, i-ABS 1
    7 ISIBAMBA I-PVC, i-ABS 1
    8 ISIKURU I-SS304,STEEL 1



    Ithebula lokuqhathanisa lepharamitha yosayizi wemodeli

    DIMENSION Iyunithi
    INDLELA DN 15 20 25 32 40 50 65 80 100
    SIZE 1/2" 3/4" 1" 1-1/4" 1-1/2" 2" 2-1/2" 3" 4" Intshi
    thd./in I-NPT 14 14 11.5 11.5 11.5 11.5 8 8 8 mm
    I-BSPT 14 14 11 11 11 11 11 11 11 mm
    I-JIS I 20 20 24 26 30 31 45 48 53 mm
    d1 22.3 26.3 32.33 38.43 48.46 60.56 76.6 89.6 114.7 mm
    d2 21.7 25.7 31.67 37.57 47.54 59.44 75.87 88.83 113.98 mm
    I-ANSI I 18 20 24 26 30 31 45 48 53 mm
    d1 21.54 26.87 33.65 42.42 48.56 60.63 73.38 89.31 114.76 mm
    d2 21.23 26.57 33.27 42.04 48.11 60.17 72.85 88.7 114.07 mm
    I-DIN I 18 20 24 26 30 31 45 48 53 mm
    d1 20.3 25.3 32.3 40.3 50.3 63.3 75.3 90.3 110.4 mm
    d2 20 25 32 40 50 63 75 90 110 mm
    d 15 19 24 30 34 45 55 70 85 mm
    H 37 55 66 73 81 91 99 121 134 mm
    A 68 80 94 100 110 136 170 210 236 mm
    L 77 91 103 111 123 146 178 210 255 mm
    D 32 37.5 44 52 60 74 93 110 135 mm
